Round, Square and Stretched Displays

Vivisign Special Displays series includes distinctive round, square, and stretched displays to accommodate different application spaces and installation flexibility, which allows them to be placed at station platforms and in train cabins to display transportation information and advertisements, or in retail stores and restaurants to broadcast product and discount information. The new form factor displays are uniquely suited to yield better effectiveness in space usage and foster an experiential viewing experience.

Manufactured with “Native” Shape and Size

• Native photomask production ensuring enhanced quality, durability and longevity
• High standard LCD production process and high quality assurance
• Customized sizes and shapes for various applications

Customized Options for Diverse Applications

• Vivisign Speical Displays series includes distinctive round, square, and stretched displays in a variety of standard sizes from 12.3” to 88”.
• Stretch displays are being used in mass transport hubs, as well as retail stores and restaurants. The ultra-wide aspect ratios are perfect for transport schedule and advertising displays.
• Square displays enable designers to better fit high-impact digital screens into visual layouts for retail stores and QSR operations with space limits.
• Round displays introduce eye-catc

Key Features

Non-Glare Panels (>25% haze)

Ultra-Wide Aspect Ratio

High Brightness (700 nit)

Narrow Bezel

Full HD Resolution

Android Media Player

24/7 Commercial Grade

Landscape or Portrait

Dual Integrated Speakers

LCD Monitor with HDMI IN

8.8” Stretched Display

Outline Size: 238.7*67.3*21.3mm

LCD Panel: Resolution: 1920*480 | Brightness: 600nits | AA Area: 218.88*54.72mm | Surface Treatment: –

Optional: LCD Monitor | Android OS

16.4” Stretched Display

Outline Size: 439*96*36mm

LCD Panel: Resolution: 1366*238 | Brightness: 500nits | AA Area: 409.8*71.4mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

19” Stretched Display

Outline Size: 503.5*121.5*36mm

LCD Panel: Resolution: 1920*360 | Brightness: 300nits | AA Area: 476.64*89.37mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

23.1” Stretched Display

Outline Size: 597.4*60.4*15mm

LCD Panel: Resolution: 1920*158 | Brightness: 500nits | AA Area: 585.6*48.19mm | Surface Treatment: AG, Haze 1%

Optional: LCD Monitor | Android OS

24” Stretched Display

Outline Size: 625.2*142.1*46.5mm

LCD Panel: Resolution: 1920*360 | Brightness: 300nits | AA Area: 597.888*112.104mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

28” Stretched Display

Outline Size: 724.6*158.5*52mm

LCD Panel: Resolution: 1920*360 | Brightness: 700nits | AA Area: 698.4*132.3mm | Surface Treatment: AG, Haze 2%

Optional: LCD Monitor | Android OS

28.6” Stretched Display

Outline Size: 724.6*222.63*52mm

LCD Panel: Resolution: 1920*540 | Brightness: 700nits | AA Area: 698.4*196.425mm | Surface Treatment: AG, Haze 2%

Optional: LCD Monitor | Android OS

29” Stretched Display

Outline Size: 724*229*52mm

LCD Panel: Resolution: 1920*540 | Brightness: 700nits | AA Area: 705.6*198.45mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

29.4” Stretched Display

Outline Size: 724.6*288.1*52mm

LCD Panel: Resolution: 1920*720 | Brightness: 700nits | AA Area: 698.4*261.9mm | Surface Treatment: –

Optional: LCD Monitor | Android OS

35” Stretched Display

Outline Size: 891.6*60.4*16mm

LCD Panel: Resolution: 2880*158 | Brightness: 400nits | AA Area: 878.4*48.19mm | Surface Treatment: AG, Haze 40%

Optional: LCD Monitor | Android OS

36” Stretched Display

Outline Size: 900.5*270.7*34.1mm

LCD Panel: Resolution: 1920*532 | Brightness: 500nits | AA Area: 878*239mm | Surface Treatment: AG, Haze 1%

Optional: LCD Monitor | Android OS

37” Stretched Display

Outline Size: 930.52*280.54*52mm

LCD Panel: Resolution: 1920*540 | Brightness: 700nits | AA Area: 904.32*254.34mm | Surface Treatment: AG, Haze 44%

Optional: LCD Monitor | Android OS

36.6” Stretched Display

Outline Size: 960*174.35*52mm

LCD Panel: Resolution: 1920*290 | Brightness: 700nits | AA Area: 919.3*138.85mm | Surface Treatment: AG, Haze 1%

Optional: LCD Monitor | Android OS

37.8” Stretched Display

Outline Size: 978.84*72.41*20mm

LCD Panel: Resolution: 2880*158 | Brightness: 700nits | AA Area: 959.04*52.614mm | Surface Treatment: –

Optional: LCD Monitor | Android OS

42” Stretched Display

Outline Size: 1067.3*287.5*52.2mm

LCD Panel: Resolution: 1920*480 | Brightness: 700nits | AA Area: 1039.68*259.92mm | Surface Treatment: AG, Haze 44%

Optional: LCD Monitor | Android OS

43.8” Stretched Display

Outline Size: 1098.2*328.2*52.2mm

LCD Panel: Resolution: 3840*1080 | Brightness: 700nits | AA Area: 1071*301mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

46.6” Stretched Display

Outline Size: 1202.8*53.59*21mm

LCD Panel: Resolution: 3840*120 | Brightness: 500nits | AA Area: 1183.68*36.99mm | Surface Treatment: AG, Haze 3%

Optional: LCD Monitor | Android OS

47” Stretched Display

Outline Size: 1208*72.6*19.5mm

LCD Panel: Resolution: 3840*180 | Brightness: 500nits | AA Area: 1192.3*55.89mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

47.1” Stretched Display

Outline Size: 1211.60*67.5*25.2mm

LCD Panel: Resolution: 3840*160 | Brightness: 500nits | AA Area: 1196.16*49.84mm | Surface Treatment: AG, Haze 25%

Optional: LCD Monitor | Android OS

48” Stretched Display

Outline Size: TBD

LCD Panel: Resolution: 3840*720 | Brightness: 1000nits | AA Area: 1194.05*223.884mm | Surface Treatment: AG, Haze 1%

Optional: LCD Monitor | Android OS

48.5” Stretched Display

Outline Size: 1235.8*253*52mm

LCD Panel: Resolution: 1920*360 | Brightness: 700nits | AA Area: 1209.6*226.8mm | Surface Treatment: –

Optional: LCD Monitor | Android OS

49.5” Stretched Display

Outline Size: 1235.8*366.4*52mm

LCD Panel: Resolution: 1920*540 | Brightness: 700nits | AA Area: 1209.6*340.2mm | Surface Treatment: AG, Haze 2%

Optional: LCD Monitor | Android OS
