Industrial TFT Panels and TFTs in sizes ranging from 10.1″ to 27″
Industrial TFT Panels, Industrial grade LCD Panel
Vivisign provides BOE/AUO Industrial TFT Panels and TFTs in sizes ranging from 6.5″ to 27″ providing an excellent price-performance ratio with excellent.
Features of Industrial TFT Panels are:
- Industrial TFT displays
- Excellent price-performance ratio
- Long-term availability
- Extended temperature range
TFT panel driver boards available – VGA, DVI and video input cards to drive a wide range of TFT panels
BOE | Rugged & Reliable Industrial TFT Panels
Size | Part Number
Working Temp.
Outline Size (mm)
Resolution
Brightness
Interface
10.1” | EV101WXM-N10
-20 ~ 70 °C
228.6(W)×149.2(H)×6(D)
1280(RGB)×800
400 (Typ.)
LVDS
10.1” | GV101WXM-N85
-20 ~ 70 °C
228.2(W)×148.85(H)×4.9(D)
1280(RGB)×800
430 (Typ.)
LVDS
10.1” | GV101WUM-N40
-20 ~ 70 °C
228.2(W)×149(H) ×2.55(D)
1920(RGB)×1200
1000 (Typ.)
eDP
12.1” | EV121X0M-N10
-20 ~ 70 °C
260.5(W)×204(H)×9.2(D)
1024(RGB)×768
500 (Typ.)
LVDS
12.1” | PV121X0M-N10
-20 ~ 70 °C
260.5(W)×204(H)×9.2(D)
1024(RGB)×768
500 (Typ.)
LVDS
15” | DV150X0M-N10
-20 ~ 70 °C
326.5(W)×253.5(H)×10(D)
1024(RGB)×768
350 (Typ.)
LVDS
15” | DV150X0M-N12
-20 ~ 70 °C
326.5(W)×253.5(H)×9.7(D)
1024(RGB)×768
350 (Typ.)
eDP
15” | DV150X0M-N16
-20 ~ 70 °C
326.5(W)×253.5(H)×10.4(D)
1024(RGB)×768
600 (Typ.)
LVDS
15.6” | EV156FHM-N10
0 ~ 60 °C
363.8(W)×216(H)×9.9(D)
1920(RGB)×1080
500 (Typ.)
eDP
15.6” | EV156FHM-N11
0 ~ 70 °C
363.8(W)×216(H)×9.9(D)
1920(RGB)×1080
500 (Typ.)
LVDS
17” | DV170E0M-N30
-20 ~ 70 °C
358.5(W)×296.5(H)×10.8(D)
1280(RGB)×1024
500 (Typ.)
LVDS
18.5” | GV185FHM-N10
-30 ~ 80 °C
430.4(W)×254.6(H)×12.5(D)
1920(RGB)×1080
350 (Typ.)
LVDS
19” | ZV190E0M-N10
-20 ~ 70 °C
396(W)×324(H)×13.38(D)
1280(RGB)×1024
450 (Typ.)
LVDS
21.5” | GV215FHM-N10
-20 ~ 70 °C
485.6(W)×292.2(H)×11.2(D)
1920(RGB)×1080
350 (Typ.)
LVDS
21.5” | DV215FHM-R10
-20 ~ 85 °C
499(W)×286.2(H)×15.2(D)
1920(RGB)×1080
1500 (Typ.)
LVDS
