RD-M | RD-MT Series
23.6” Round LCD Digital Signage Display, 1500nits Ultra High Brightness, PCAP Touch Round Displays
A perfect round LCD digital signage solution for Bars, Hotels and Retail environment.
Key Features
- Round LCD Panel Resolution: 1280*1280 for RD236M
- 1500nits ultra high brightness & Viewing Angle (H/V): 178/178
- LED Life time: >50K hours
- RD236M offer higher haze panels that help reduce reflections without adversley affecting the image quality. Anti-glare coatings can also improve the perceived contrast of the display.
- Outline Dimension: 662.584*662.584mm | Display Area: 600.384*600.384mm
- OPT.1: LCD Monitor with HDMI IN/VGA IN
- OPT.2: Integrated with Android signage player
RD236M 23.6” Round LCD Display | 1500nits
Key Features:
- 23.6” Round LCD Panel: BOE LCD Panel | 1280*1280 Resolution | 178/178 Viewing Angle
- 1500Nits high brightness for indoor high lighting environment
- 24/7 working hours, LED lifespan >50,000hours
- OPT. 1: LCD Monitor Format available | HDMI IN
- OPT. 2: Built-in Android signage player
Usage: Indoor high lighting environment
RD236MT 23.6” PCAP Touch Round LCD Display | 1500nits
Key Features:
- 23.6” Round LCD Panel: BOE LCD Panel | 1280*1280 Resolution | 178/178 Viewing Angle
- 1500Nits high brightness for indoor high lighting environment
- PCAP Touch Panel, 10 points touch
- 24/7 working hours, LED lifespan >50,000hours
- OPT. 1: LCD Monitor Format available | HDMI IN
- OPT. 2: Built-in Android signage player
Usage: Indoor high lighting environment
RD157M 15.7” Round LCD Display | 700nits
Key Features:
- 15.7” Round LCD Panel: AUO LCD Panel | 960*960 Resolution | 178/178 Viewing Angle
- 700Nits high brightness for indoor high lighting environment
- 24/7 working hours, LED lifespan >50,000hours
- AA Area (mm): 400 x 400
- Outline Size (mm): 452.95 x 452.95 x D
- OPT. 1: LCD Monitor Format available | HDMI IN
- OPT. 2: Built-in Android signage player
Usage: Indoor high lighting environment
RD5MT 5” PCAP Touch Round LCD Monitor | 350nits
Key Features:
- 5” Round LCD Panel: TFT LCD Panel | 1080*1080 Resolution | 160/160 Viewing Angle
- 350Nits high brightness for indoor environment
- PCAP Touch Panel, 10 points touch
- 24/7 working hours, LED lifespan >30,000hours
- OPT. 1: LCD Monitor Format available | HDMI IN
Usage: Indoor environment
At a Glance
ViviSign 23.6” Circular LCD Displays are consisting of 23.6” cicular panel with diameter 1280 pixel active area, power board and AD board or Android signage player board as required and are a totally new shape and format for digital signage applications.
Format 1: 23.6” Cicular Displays can be as LCD monitor, with HDMI IN and VGA IN, it allows users to connect any external media player.
Format 2:23.6” Round Displays, integrated Android media player with RK3568 Quad-coe Cortex A55 (up to 1.8GHz) CPU and Mali-G52 GPU plus Android OS 11 platform, provides a high performance platform, allows any 3rd party CMS to run for digital signage applications.
Features
Round TFT-LCD Module
23.6” Round TFT-LCD Module with 600.384mm diameter and 848*848 resolution.
1500nits High Brightness
Commercial grade ultra-high brightness round LCD panels (1500cd/m²) ensures that content really stands out, even the brightest direct sunlight.
Wide Viewing Angle
Full viewing angle (H:178/V:178) allows viewers can watch the contents from any angle without distortion and color wash.
OPT.: PCAP Touch Screen
Optimum sensitivity to touch gestures and rapid response times ensure that users have a smooth, effortless experience.
OPT.1: LCD Monitor
With LCD Monitor controller board, HDMI IN allows to connect to any external media player.
OPT.2: Built-in Android Player
Integrated with Android Signage Player, ready-to-use digital signage software, also support 3rd party APK.
Dual Integrated Speakers
Integrated with dual speakers inside, the signage displays can deliver a stereo sound while displaying the videos.
24/7 Continuous Use
Commercial grade design allows digital signage displays run 24×7 smoothly.
Specifications
23.6 Inch – RD236M
Display Area
600.384*600.384mm
Unit Size (W*H*D)
657*657*47.33mm
LCD Panel
Resolution
1280 x 1280
Brightness
1500nit
Contrast Ratio
1000:1
Viewing Angle
178/178/178/178
Power
Power Input
AC 100-240V
Power Consumption
120W
Android PC
CPU
Quad-core Cortex-A55
GPU
Mali-G52
RAM/ROM/OS
2GB / 16GB / Android OS 11
Network
LAN / Wi-Fi
